36Vdc to 24Vdc（1-21A）dc to dc power converter|36Vdc to 24Vdc（1-21A）dc dc power module|36Vdc to 24Vdc（1-21A）dc dc up converter

36Vdc to 24Vdc（1-21A）
Product Model : YKDD36S24**Series
Product Information :
A.Input Voltage:36vdc(30-60vdc) B.Output Voltage:24V C.Output Current:5A D.Non-Isolated design /Constant voltage design/Waterproof E.High efficiency

1. Constant voltage design

2. SMT Process

3. Non-Isolated Module

4. 2:1 wide input range

5. Built-in EMI filter, low ripple noise

6. 100% full load burn-in test

7. Certificates :CE

8. Waterproof level : IP67

9. Protections: Short circuit/Over load /voltage / Automatic recovery work

10. Ultra compact size, light weight , high reliability

11. 1 year warranty, lifetime up to 100,000 hours

1. Electric motors, Electric fans , Trucks, Golf Carts ,Forklifts

2. Navigation, surveillance, Air conditioning

3. LED car display, DVD, LED lights, Audio

4. Wind Power System, Solar Power System, Photo voltaic energy

BUCK DC-DC CONVERTER MODEL LIST

BOOST DC-DC CONVERTER MODEL LIST

BUCK& BOOST DC-DC CONVERTER MODEL LIST

ISOLATED BUCK DC-DC CONVERTER MODEL LIST

AC-DC CONVERTER MODEL LIST

Model	YK-DD36S245	YK-DD36S2410		YK-DD36S2421
Input
Input voltage	36Vdc
Rate voltage	30-60v
Output
Rate voltage	24vdc±0.25vdc
Rate current	5A	10A		21A
Rate power	120W	240W		504W
Conversion efficiency	>90%
Voltage regulation	±1%
Load regulation	± 2%
Ripple (Full load test)	< 150mV
No-load current	< 60mA
Working temperature	-20~80℃
Waterproof rating	IP67
USB Portoption (9 types design for option)	Dual cable +Dual USB Dual cable output+ dual USB with install hole Dual cable + Dual USB female port Dual USB female port micro port mini P5 PORT USB female port with install hole USB Female port USB+MICRO
Protection	Over-current / voltage / load protection
	Overheat protection
	Lower voltage protection
	Intrusion protection
	Short-circuit protection and automatic recovery
	Full waterproof potting
Dimension	Large aluminum shell		SIZE : W74H74D32mm		NW: 250g
Install cable	13-15(cm)
